LA Downtown Climate Monitor - Real-time Weather & Environmental Data

Current Time

--:--:--

Temperature

--°C

No data

Pressure

-- hPa

No data

Humidity

--%

No data

🌡️ LA Downtown Temperature History

📊 Atmospheric Pressure History

💧 Relative Humidity History

LA Downtown Climate Statistics (Last 24 Hours)

Temperature

Min: --°C Max: --°C Avg: --°C

Pressure

Min: -- hPa Max: -- hPa Avg: -- hPa

Humidity

Min: --% Max: --% Avg: --%

🔬 Sensor Specifications

Sensirion SHT35

Temperature & Humidity Sensor

Temperature Range: -40°C to +125°C

Temperature Accuracy: ±0.3°C (typical)

Humidity Range: 0% to 100% RH

Humidity Accuracy: ±2% RH (typical)

Primary sensor for temperature and humidity measurements

Bosch BMP388

Barometric Pressure & Temperature Sensor

Pressure Range: 300 to 1250 hPa

Pressure Accuracy: ±0.08 hPa (typical)

Temperature Range: -40°C to +85°C

Temperature Accuracy: ±0.5°C (typical)

Primary sensor for atmospheric pressure measurements

Measurement System

This climate monitoring station uses high-precision industrial-grade sensors connected via I²C bus to an ESP32-C6 microcontroller. Data is collected every 30 seconds and transmitted to this server in real-time. The system provides accurate environmental monitoring for Los Angeles Downtown with professional-grade sensor accuracy.

Data Update Frequency: Every 30 seconds
Data Retention: 24 hours of historical data
Sensor Calibration: Factory calibrated, no user calibration required
Operating Conditions: Indoor/outdoor rated sensors

📡 Public API Documentation

This API provides public read-only access to real-time environmental sensor data from Los Angeles Downtown. All endpoints are CORS-enabled and require no authentication. Data is updated every 30 seconds and retained for 24 hours.

GET /api/data.php?action=get

Retrieve sensor data from the last 24 hours

Response Format: JSON

Data Retention: Only last 24 hours of data is kept. Older data is automatically removed.

Response Fields:

temperature (float) - Temperature in Celsius
pressure (float) - Pressure in hPa
humidity (float) - Humidity percentage
latitude (float, optional) - Latitude in decimal degrees
longitude (float, optional) - Longitude in decimal degrees
timestamp (integer) - Unix timestamp (64-bit, UTC)
id (string) - Unique identifier

Example Response:

{
  "success": true,
  "latest": {
    "temperature": 23.5,
    "pressure": 1013.25,
    "humidity": 45.0,
    "latitude": 34.0522,
    "longitude": -118.2437,
    "timestamp": 1704067200,
    "id": "67890abcdef12345"
  },
  "history": [
    {
      "temperature": 23.5,
      "pressure": 1013.25,
      "humidity": 45.0,
      "latitude": 34.0522,
      "longitude": -118.2437,
      "timestamp": 1704067200,
      "id": "67890abcdef12345"
    }
  ],
  "count": 1440
}

Important Notes:

Timestamps: All timestamps are Unix timestamps (64-bit integers) in UTC. Convert to local time for display.
CORS: All endpoints support CORS and can be accessed from any origin.
Rate Limiting: Currently no rate limiting is enforced, but please use responsibly.
Data Format: Temperature in Celsius, pressure in hPa (hectopascals), humidity as percentage (0-100).
Location Data: Location coordinates (latitude/longitude) are included in API responses if provided by the sensor.
